Specifications

• ENGINE

  add remove
  • Cylinders:
    3
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    82
  • Torque (Ft Lbs):
    58.3
  • Torque RPM:
    6500
  • Bore (mm):
    74
  • Stroke (mm):
    69.7
  • Displacement (cc):
    900
  • Compression Ratio:
    11:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Primary Drive (Rear Wheel):
    Shaft
  • Reverse:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    92.6
  • Width (in):
    59.9
  • Height (in):
    42.2
  • Wheelbase (in):
    67.3
  • Ground Clearance (in):
    4
  • Dry Weight (lbs):
    642
  • Payload Capacity (lbs):
    438.7
  • Fuel Capacity (gal):
    5.3
  • Storage Capacity (cuft):
    0.2
  • Storage Capacity (l):
    7
  • Engine Displacement to Weight (cc):
    1.4
• SUSPENSION

  add remove
  • Front Suspension Type:
    Double-Wishbone
  • Front Travel (in):
    6.3
  • Rear Suspension Type:
    Single Sided Swing Arm
  • Rear Travel (in):
    6.7
  • Number Rear Shock Absorbers:
    1
  • Front Suspension Brand Name:
    KYB
  • Rear Suspension Brand Name:
    KYB
• WHEELS & TIRES

  add remove
  • Front Tire Width:
    145
  • Front Tire Aspect Ratio:
    60
  • Front Wheel Diameter:
    16
  • Rear Tire Width:
    205
  • Rear Tire Aspect Ratio:
    45
  • Rear Wheel Diameter:
    16
  • Front Tire (Full Spec):
    MC 145/60 R16 66T
  • Rear Tire (Full Spec):
    MC 205/45 R16 77T
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    10.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    8.7
